1000pcs/h Simple Design Semi-Automatic Paper Egg Tray Machine Production Line without Dryer Low Energy Consumption Small Business Idea

1000pcs/h Simple Design Semi-Automatic Paper Egg Tray Machine Production Line without Dryer Low Energy Consumption Small Business Idea

semi-automatic egg tray machine

small egg tray production line

low energy egg tray machine

Lugar de origem:

CHINA

Marca:

WANYOU

Número do modelo:

WY-1

Contacte-nos
Solicite um orçamento
Detalhes do produto
Sistema de controle:
Plc
Material do molde:
plástico ou de alumínio
Capacidade da máquina:
1000pcs/h, personalizado
Tamanho da bandeja de ovos:
295mm*295mm 30 ovos
Tipo de formação:
Sucção a vácuo
Fonte de energia:
380V/50Hz
Produto final:
Bandeja de ovos, caixa de ovos, bandeja de sapatos, bandeja de embalagem industrial, bandeja de maçã
Combustível mais seco:
Gás natural, GLP, diesel, carvão, madeira, pellets de biomassa
Destacar:

semi-automatic egg tray machine

,

small egg tray production line

,

low energy egg tray machine

Termos de pagamento e envio
Quantidade de ordem mínima
1set
Preço
USD8800/SET
Detalhes da embalagem
no recipiente
Tempo de entrega
40 dias úteis
Termos de pagamento
T/T, Western Union, MoneyGram
Habilidade da fonte
1 conjunto por mês
Descrição do produto

1000pcs/h Simple Design Semi-Automatic Paper Egg Tray Machine Production Line without Dryer Low Energy Consumption Small Business Idea


Product Information

This is  semi automatic one without dryer egg tray machine

Main sections of the paper egg tray machine:

1pulping system:

Put the waster paper into the hydraulic pulper , the paper and water will mix in hydraulic pulper ,then go to the refiner machine, refiner machine make the pulp more small and uniform ,then the pulp pump absorb the pulp to the pulp pool .after the second mix in the pulp pool, the pulp will go to the forming machine pulp tank .

1000pcs/h Simple Design Semi-Automatic Paper Egg Tray Machine Production Line without Dryer Low Energy Consumption Small Business Idea 0

  2forming system

The Egg Tray Molding Forming System consists of various equipment and dies.

The wet forming section consists of a series of wire screen covered wet forming dies mounted on a molding drum, and a matching set of transfer dies mounted on a transfer mechanism.

The egg tray forming die is made up of rigid corrosive resistant metal or ABS engineering plastic and consists of many component parts that are drilled with small drainage holes and covered by prior to formed stainless steel screens.

Simple structure egg tray machine with cheaper investment

1*2 molds paper egg tray machine 700pcs/h capacity forming part

1000pcs/h Simple Design Semi-Automatic Paper Egg Tray Machine Production Line without Dryer Low Energy Consumption Small Business Idea 1

1*3 molds paper egg tray machine 1000pcs/h capacity forming part

1000pcs/h Simple Design Semi-Automatic Paper Egg Tray Machine Production Line without Dryer Low Energy Consumption Small Business Idea 2

1*4 molds paper egg tray machine 1500pcs/h capacity forming part


1000pcs/h Simple Design Semi-Automatic Paper Egg Tray Machine Production Line without Dryer Low Energy Consumption Small Business Idea 3


Various capacity egg tray machine / egg tray production line we can make

Egg tray mould quantity

1pcs

2pcs

3pcs

4pcs

Raw material

Waste paper

Waste paper

Waste paper

Waste paper

Output for egg tray

350pcs/hour

700pcs/hour

1000pcs/hour

1300pcs/hour

Net weight per piece (gram)

70g-75g

70g-75g

70g-75g

70g-75g

The volume of waste paper consumed

0.025ton / hour

0.06ton / hour

0.1ton / hour

0.13ton / hour

The volume of water consumed

0.05ton / hour



0.15ton / hour

0.2ton / hour

Operators number

2-3workers

3-4workers

4-6workers

4-6workers

Area of workshop

More than 200M²

More than 240M²

More than 240M²

More than 240M²

Capacity of power

25KW

40KW

50KW

60KW

1000pcs/h capacity 3 molds egg tray machine technical data

Egg Tray Mold Quantity

3pcs

Raw material

Waste paper

Egg tray Capacity

1000pcs/hour

Net weight per piece (gram)

70g-75g

Waste paper consumption

75kg / hour

Water Consumption

0.15ton / hour

Natural Gas Consumption of Dryer

35cbm/h

Worker requirement

4-6workers

Machine Length

7m-25m

Machine weight

8-20tons

Power Requirement

Without dryer

40KW

With dryer

60KW

Area of workshop

Without dryer

More than 120 M²

With dryer, dryer-16m

More than300M²

Container Requirement

Without dryer

40ft*1

With dryer

40ft*3

Remarks:

1. The egg tray Capacity calculated base on 30-packed egg tray(size 300x300mm, weight 70g~75g).

2. Workshop size is for reference only and could be adjusted according to actual size of client’s plant.

End product of paper egg tray machine

1000pcs/h Simple Design Semi-Automatic Paper Egg Tray Machine Production Line without Dryer Low Energy Consumption Small Business Idea 4


1000pcs/h Simple Design Semi-Automatic Paper Egg Tray Machine Production Line without Dryer Low Energy Consumption Small Business Idea 5

1000pcs/h Simple Design Semi-Automatic Paper Egg Tray Machine Production Line without Dryer Low Energy Consumption Small Business Idea 6

Payment Terms

Delivery Time: 40 working days after getting payment

Payment Terms: 40% T/T prepayment in advance.

               60% before delivery by T/T.

Warranty time

1year after the Egg tray machine received.

Terms of delivery

EXW Jinan, China

Time of payment

When the deposit is paid, the machine will begin to be produced. And the balance should be paid by the consignee (the buyer) before the delivery.
